12kW-10kWh Mobile Power Station

12kW-10kWh Mobile Power Station is a high-capacity, movable energy storage solution designed for reliable off-grid power, backup applications, and versatile energy management. Featuring a robust LiFePO4 battery configuration (3.2V 206Ah / 1P16S), this system delivers a nominal energy of 10kWh and a rated power output of 12kW. It supports flexible AC output voltages (110V/120V/220V/230V) and a wide AC input range of 150-264Vac, making it highly adaptable to different regional power standards.

Phone: +8613589069779

WhatsApp: +8613589069779

E-mail: peter@luminpow.com

PRODUCT DESCRIPTION

12kW-10kWh Mobile Power Station

12kW-10kWh Mobile Power Station
Battery Type	LiFePO₄
Nominal Energy	10kWh
Configuration	3.2V206Ah/1P16S
Rated power	12kW
AC output voltage	110Vac/120Vac/220/230Vac
AC input voltage	150-264Vac
AC input frequency	45~50Hz
AC charging power (max.)	6.2kW
Max. PV input power	6.2kW
PV input voltage	MAX 120V
Maximum PV input current	30A
Cycle Life (@25℃,90%DOD)[1]	≥6000Cycles
Warranty Period[2]	5+5 years
Display Mode	Green light: system running / Red light: system alarm
PERFORMANCE SPECIFICATIONS
Weight(kg)	165kg
Dimension(WDH)	750541690mm
Installation Method	Movable
IP Rating	IP54
SECURITY AND CERTIFICATION
Certification(Pack)	UN38.3,MSDS,IEC62619(CB),CE-EMC,IEC63056
Certification(Cell)	UN38.3,MSDS,IEC62619,CE,UL1973,UL2054
Protection	BMS and breaker
ENVIRONMENTAL SPECIFICATIONS
Charging Temperature Range	0℃~60℃
Discharging Temperature Range	-20℃~60℃
Operating Temperature	-30~60℃ (derating above 45℃)
Storage Temperature	0~35℃
Operating Humidity	≤90%(non-condensing)
Operating Altitude	≤2000m
